The JMAZ ATTCO BEAM 230 features a powerful 231W OSRAM SIRIUS HRI discharge lamp, delivering up to 164,230 lux at 10m. It includes an 11-color wheel, 16 static gobos, dual prism wheels, and a frost filter for versatile effects.
With a 2.5° beam angle, electronic focus (2.5m-30m), and DMX512 or RF remote control, it’s ideal for impactful lighting. Includes RF remote, Omega bracket, powerCON, DMX cable, and safety accessories.
ATTCO BEAM 230
SKU: JZ3013
$999.95Price
Excluding Sales Tax
Light Source
- 231W OSRAM SIRIUS HRI Discharge Lamp
- Lux: 164,230 lx @ 10m , 73,170 lx @ 15m
- Life Expectancy: 2,000 hrs
Color System
- Color Wheel: 11 colors + Open
Optics
- Beam Angle: 2.5°
- Electronic Motorized Focus: 2.5m-30m
- Lens Diameter: 136mm
- Lens Type: Anti-Reflections
Dynamic Effect
- Static Gobos: 16 + Open
- Dual Prism Wheel: Frist Prism 16 Facet , Second 8 Facet + 16 w/ Variable Speed
- 9 Built-In Auto/Sound Programs
- Frost Filter
- Dual Flag Mechanical Dimming
Control
- Protocols: 3-Pin In/Out DMX512, Wireless DMX
- Personalities: 2 Modes 14/16
- Wireless Control: RF Remote
- Display: 2.4″ TFT LCD Display
Electronics
- Dimmer:0-100% Linear Dimmer
- Operating Temperature:-35° C to 45° C
Body
- Quick-Lock Omega Bracket
- Pan Angle: 630°
- Title Angle: 270°
- High Temperature Engineered Plastic and Cast Aluminum Casing
Physical
- Cooling: Fan
- Pan/Tilt: 8/16 bit smooth
- powerCON In/Out
Electrical
- Max Power Consumption: 190W
- Input Voltage: AC91-260V, 50/60Hz
Box Content
- 2 x Omega Brackets
- 1 x DMX Cable
- 1 x powerCON Cable
- 1 x RF Remote
- 1 x Safety Cable
- 1 x User Manual
Item Dimensions & Weight
- Dimensions: 15.2″ x 15″ x 8.7″
- Weight: 30.6 lbs
UPC
Black: 093674449565
White: 618528606989
Warranty
2 Years
